Software Deployment Model

OS inventory

The model uses the needed subset of CWM 1.1 SoftwareDeployment, section 5.7. Each entity maps to its own table. IDs are database identity keys; references use those IDs rather than IP addresses.

Entity and table	Stored attributes and relationships
ModelElement	Auto-increment `id`; `name`; optional `namespace`; inherited `taggedValue` collection
TaggedValue	Technical `id`; `tag`, `value`, optional `modelElement` reference
Namespace	Shared `id` referencing ModelElement; `ownedElement` is the inverse of `ModelElement.namespace`
Package	Shared Namespace identity; target of `DataManager.dataPackage`
SoftwareSystem	Shared Package identity; `type`, `subtype`, `supplier`, `version`
Component	Shared Namespace identity; inherited `namespace` identifies its owning SoftwareSystem when present; `deployment` is the inverse of `DeployedComponent.component`
DeployedComponent	Shared Package identity; `pathname`, required `machine` and `component` references
DataProvider	Shared DataManager identity; client deployment
ProviderConnection	Shared ModelElement identity; provider owner and server reference
DataManager	Shared DeployedComponent identity; `dataPackage` references through DataManagerDataPackage
Catalog	Shared Package identity; database name inherited from ModelElement
Machine	Shared Namespace identity; `deployedComponent` is the collection of deployments referencing the machine

The stored path is SoftwareSystem → Component → DeployedComponent → Machine. A SoftwareSystem owns zero or more Components; a Component has zero or one owning namespace. A Component has zero or more deployments, each referencing exactly one Component and exactly one Machine.

Ownership is stored on ModelElement.namespace, with a foreign key to Namespace.id. Namespace.ownedElement is derived by reading that inverse relationship. Both fields stay on their owning parent classes. Each adopted subclass shares its parent’s ID through foreign keys. The scanner assigns a Component’s namespace to its SoftwareSystem and a DeployedComponent’s namespace to its Machine.

ModelElement, Namespace, and Package supply the adopted core hierarchy. Intermediate classes with no currently needed fields, such as Classifier and Subsystem, remain omitted; entities inherit from their nearest implemented ancestor. The newly needed name attribute stays on ModelElement. There is no DeployedSoftwareSystem entity or association table in this subset.

MariaDB discovery creates a deployed DataManager linked to relational Catalog objects through DataManagerDataPackage. DataProvider describes client software, rather than the MariaDB server itself. See Schema Notes for association multiplicities and naming decisions.

Discovery mapping

Nmap’s structured OS classification supplies:

SoftwareSystem attribute	Value
`type`	`OS`
`subtype`	Nmap `osfamily`
`supplier`	Nmap `vendor`, or null if absent
`version`	Nmap `osgen`, or null if absent

The scanner accepts a classification only when Nmap reports 100% accuracy and all classifications at that accuracy agree on these fields. Approximate, conflicting, and missing classifications leave the stored OS unchanged. This is a fingerprint result, not a verified product release. Generation strings such as 6.X are retained as reported; distribution names and exact versions are not inferred from the freeform fingerprint description.

The scanner represents the OS deployment using pathname="/", our current modeling convention. Nmap does not inspect the remote filesystem or verify that path. Identical OS classifications share a SoftwareSystem and Component; each machine gets its own DeployedComponent. Repeat scans reuse those records. A changed classification updates that machine’s deployment without changing another machine’s software definition. Unused definitions and their Components are pruned at the end of each workload.

After the Nmap passes, hostname collection also reads the host’s Linux os-release file through the SSH interface (directly for the local machine). The host-reported release replaces the Nmap classification for that machine’s existing / deployment when available:

SoftwareSystem attribute	Host-reported value
`type`	`linux`
`subtype`	`ID` (required), e.g. `debian`
`supplier`	`Debian` when `ID=debian`; otherwise `VENDOR_NAME`, or null if absent
`version`	For Debian, `DEBIAN_VERSION_FULL`, falling back to `VERSION_ID`; otherwise `VERSION_ID`

VERSION_CODENAME is stored as a TaggedValue on the SoftwareSystem, through its inherited ModelElement identity: tag="VERSION_CODENAME", value="trixie". The relationship is declared on ModelElement, not duplicated on SoftwareSystem. Only the needed TaggedValue attributes are adopted; its unused Stereotype relationship and attribute-free Element parent remain omitted.

Use /etc/os-release when present, otherwise /usr/lib/os-release. Do not infer suppliers for other distributions or substitute a kernel version for the product release. Hosts without readable, valid release data retain the current observation, including any classification collected by Nmap in that scan. Each scan runs Nmap first and host-reported collection afterward.

The API returns Machine.deployedComponent as a list of deployed component IDs. The same response includes a softwareDeployments display projection, joining DeployedComponent through Component’s owning ModelElement to SoftwareSystem and its codename tag. This projection adds no entity or schema attributes. The graph draws a rounded software rectangle inside its containing machine, labelled from subtype, optional codename, and version, e.g. Debian (trixie) 13.6.

Reporting

This query follows the stored relationships from a machine to its OS:

SELECT m.id, m.ipAddress, m.hostName, dc.pathname,
       ss.type, ss.subtype, ss.supplier, ss.version
FROM Machine AS m
JOIN DeployedComponent AS dc ON dc.machine = m.id
JOIN Component AS c ON c.id = dc.component
JOIN ModelElement AS me ON me.id = c.id
JOIN SoftwareSystem AS ss ON ss.id = me.namespace
WHERE ss.type IN ('OS', 'linux');

Application discovery

For the constants-file convention, registration steps, and individual CMDB_* references, see App discovery settings. That guide is the starting point for developers updating an app.

The discovered version belongs to SoftwareSystem; its Component is linked to a DeployedComponent on the host with pathname="/opt/prod/mycount". Repeated observations reuse the deployment. Definitions and components for the same application release can be shared across hosts, while hosts with different versions retain distinct release references. The manually created unversioned definition is populated on the first successful discovery. Application names supply labels in Inventory and the Applications table.

Inventory workloads check applications on each responding host after its host details and MariaDB inventory are collected. Re-Scan Applications checks all inventoried hosts without running network or OS discovery. Both use the coordinator’s single worker and FIFO request queue; workloads run sequentially. Add Application queues discovery for the new definition on all inventoried hosts. The Status Messages box reports each checked host’s short hostname (or IP) and application with its recorded version, or not detected / read failed, on one line.

Missing directories, missing files, or invalid VERSION values make no changes to inventory. Host access failures preserve records and allow the remaining hosts to be checked. The worker reports Scan complete when scanning finishes, including when individual application reads fail. Existing deployments are retained. At the end of every workload, undeployed SoftwareSystems and their unused Components are pruned and each removal is recorded in Status Messages. Newly added definitions survive earlier workloads until their own queued discovery attempt ends. An application that has never been deployed is then pruned if discovery records no deployment.

Network declarations (coming)

The CMDB_NETWORK app developer guide covers the application-side listener standard. Network declarations are not yet collected, stored, or displayed by CMDB.

MariaDB discovery

After host inventory, SSHDb verifies or provisions agent access and executes schema/mariadb-inventory.sql over the default local MariaDB socket. It collects VERSION(), @@datadir, and database names from information_schema.SCHEMATA. The local machine uses the same command path as remote machines.

SoftwareSystem uses type="DBMS", subtype="MariaDB", supplier="MariaDB" (the inventory convention), and the complete server-reported version string. Its Component is deployed as a DataManager on the discovered Machine. The DataManager inherits pathname, populated with the reported data directory. Machine ID and that path identify the observed instance across version changes. Only the default socket instance is queried in this increment.

Each database, including system databases, becomes a Catalog with its exact name on ModelElement. Its namespace is the DataManager, which keeps identical names on different instances distinct. DataManagerDataPackage links the manager to each catalog. Repeated observations reuse identities; new releases share a new software definition without changing another machine’s release. Existing catalogs absent from a later observation are retained for now.
